| Category | Specification |
|---|---|
| General Specifications | |
| Maximum Lifting Capacity | 75 tons |
| Maximum Lifting Moment | 2850 kN.m (approx.) |
| Boom & Jib | |
| Main Boom | 6-section, U-shaped telescopic boom |
| Boom Length | 13.5 m to 48.0 m (fully extended) |
| Lattice Jib | Optional, typically 9.5 m to 17.5 m |
| Max. Tip Height (with jib) | Up to ~65.5 meters |
| Chassis & Mobility | |
| Carrier Configuration | All-terrain truck chassis |
| Drive Configuration | 8×4 or 8×6 |
| Max. Travel Speed | ~70 km/h |
| Engine Model | Cummins QSM11 |
| Rated Power | 298 kW / 400 hp |
| Performance & Dimensions | |
| Max. Hoisting Speed | ~130 m/min (main winch) |
| Max. Slewing Speed | ~2.0 rpm |
| Outrigger Span | ~6.8 m (longitudinal) x ~7.0 m (vertical) |
| Overall Dimensions (LxWxH) | ~15.2 x 2.75 x 3.95 m |
| Weights | |
| Total Weight (approx.) | 48,000 kg |
Contact our sales team to get the latest pricing and inventory information for our machinery. Send us an inquiry now to help you find the right equipment quickly.
